QUBE SERIES
OIL-FREE PISTON COMPRESSORS
SOUNDPROOFED
MADE IN ITALY   l   3-YEAR WARRANTY
qube page image.png

QUBE oil-free piston compressors are designed to ensure further noise suppression of our pumping units, while maintaining their duty cycle unchanged. Its innovative TURBOVENT cooling system allows complete control of operating temperatures. Among the advantages for the user, these products have a continuous working cycle at 14 bars, the maintenance of efficiency of the pumping unit over time, an extension of the useful life of mechanical and electrical component, and a noise reduction of an additional 20 dB compared to the non-soundproofed versions.

Powered by cutting edge AXXER MOTION technology, wear-and-tear is reduced to a minimum thanks to an axial piston motion that eliminates radial forces. As a result, QUBE compressors have redifined the notion of maintenance-free. Up to a cumulative 10000 hours, pumps require no service.

The cabinets are also designed to allow easy opening for ordinary or special inspection and maintenance. QUBE compressors are available in two power ranges, 2,2 kW and 4,0 kW with air outputs ranging from 330 to 660 liters per minute. For both models there are a basic version and a version with membrane dryer, and upon request one with a 0,01 micron antibacterial filter. The 4,0 kW models are also available with 270 liter tanks, and with refrigerant cycle air drying devices.

COMMON FEATURES

  • oil free: class 0

  • thermostat

  • hour meter

  • pressure regulator

  • turbovent cooling system

  • optimized space-saving designed for tight corners and small offices

  • sturdy metal construction for extended use

  • internal sound-dampening polyurethane walls to reduce noise

  • double air outlet

  • tank automatic drain

2,20 kW

47 dB(A)

QUBE 300

OIL-FREE PISTON COMPRESSOR

.

.

  • Axxer Motion pump CSW330

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 230V - 50Hz

  • 2,20 kW (3,00 hp)

  • 1400 rpm

  • 2 cylinders

  • 330 L/min air intake

  • 200 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 47 dB(A)

  • available in other voltages and frequencies.

QUBE DRY 300 H/HS

OIL-FREE PISTON COMPRESSOR

with membrane dryer (dew point -40°C)

and 0,01µ sterilizing filter

  • Axxer Motion pump CSW330

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 230V - 50Hz

  • 2,20 kW (3,00 hp)

  • 1400 rpm

  • 2 cylinders

  • 330 L/min air intake

  • 180 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 47 dB(A)

  • available in other voltages and frequencies.

4,00 kW

54 dB(A)

QUBE 550

OIL-FREE PISTON COMPRESSOR

.

.

  • Axxer Motion pump ESW660

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 400V - 50Hz

  • 4,00 kW (5,50 hp)

  • 1400 rpm

  • 4 cylinders

  • 660 L/min air intake

  • 400 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 54 dB(A)

  • available in other voltages and frequencies.

QUBE DRY 550 H/HS

OIL-FREE PISTON COMPRESSOR

with membrane dryer (dew point -40°C)

and 0,01µ sterilizing filter

  • Axxer Motion pump ESW660

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 400V - 50Hz

  • 4,00 kW (5,50 hp)

  • 1400 rpm

  • 4 cylinders

  • 660 L/min air intake

  • 360 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 54 dB(A)

  • available in other voltages and frequencies.

4,00 kW

54 dB(A)

QUBE 550-270

OIL-FREE PISTON COMPRESSOR

.

.

  • Axxer Motion pump ESW660

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 400V - 50Hz

  • 4,00 kW (5,50 hp)

  • 1400 rpm

  • 4 cylinders

  • 660 L/min air intake

  • 400 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 270 lt. epoxy-coated steel tank

  • 54 dB(A)

  • available in other voltages and frequencies.

QUBE DRY 550-270 R

OIL-FREE PISTON COMPRESSOR

with refrigerant dryer (dew point +5°C)

  • Axxer Motion pump ESW660

  • 10000 hours maintenance overhaul

       † based on 10 bars continuous operation at 40° C.

  • 400V - 50Hz

  • 4,00 kW (5,50 hp)

  • 1400 rpm

  • 4 cylinders

  • 660 L/min air intake

  • 400 L/min @ 5 bars

  • 10 bars max. pressure

  • S1 - 100% duty cycle

  • 270 lt. epoxy-coated steel tank

  • 54 dB(A)

  • available in other voltages and frequencies.
